Minimalist design. Maximum experience.
The Series 01 is your timeless, hand-built city e-bike – just 13.5 kg, and built to last.
Mahle X20 Motor System
Compact and powerful rear-hub motor with 65 Nm torque. Delivers smooth, quiet assistance that feels natural, making every ride more fluid – even uphill or through headwinds.
Shimano 11-Speed Gearing
Precise and proven. The Shimano Deore 11-speed system gives you total control and a wide range for city terrain, climbs, and longer weekend rides.
Paint & Frame
Each frame is hand-painted in Valencia. Smooth welds, refined finishes, and minimalist lines give Series 01 its signature Scandinavian look – understated yet distinctive.
Hydraulic Braking
Formula Cura hydraulic disc brakes give you sharp, confident braking – whether you're navigating city traffic or riding in wet weather.
Integrated Lighting
Supernova lights are fully integrated and powered by the main battery. Always on when you need them, without extra charging or cabling.
Only 13.5 kg Total Weight
Fully equipped with motor, battery, and lights – yet still just 13.5 kg. One of the lightest e-bikes in its class, easy to lift, agile to ride.
Frame Design
Clean, minimalist lines. Lightweight aluminum frame with full internal cable routing and integrated front & rear lights. Designed and hand-painted in Europe.
Motor & Battery
Mahle X20 rear hub 65 Nm motor - ultra-compact, silent, and responsive.
Integrated 236 Wh battery with optional range extender (208 Wh) for up to 130+ km range.
Seamless iWoc One interface and app connectivity.
Drivetrain
Shimano GRX crankset with a 42T chainring and 170 mm crank arms, paired with Acros Urban pedals. The bike features an 11-speed Shimano GRX rear derailleur (maximum 34T), a Shimano 105 11-speed cassette (11–34), a matching Shimano 105 chain, and a Shimano Deore Rapidfire shifter.
Wheels
Prototype rims. Sapim spokes. Panaracer Gravel King tires (40 mm).
Lightweight, fast-rolling, and suitable for both urban and light gravel use.
Cockpit
Ergonomic grips, internal cabling, and custom stem setup.
Designed for comfort on longer rides and agility in city traffic.
Three ride positions available: Relaxed, Balanced, or Sport.
Brakes & Lights
Formula Cura hydraulic disc brakes - strong, silent, and easy to modulate.
Supernova front and rear lighting fully integrated into frame and system.
Connectivity
Mahle iWoc One button with Bluetooth app integration.
Weight
13.5 kg (without accessories)
Optional Accessories
Kickstand (+39 €)
Rear carrier (+119 €)
Available Sizes
S (52 cm), M (54 cm), L (56 cm), XL (58 cm)
|
SIZE FRAME |
|
S 52 |
M 54 |
L 56 |
XL 58 |
|
A |
ST length (mm) |
520 |
540 |
560 |
580 |
|
B |
TT horizontal (mm) |
528 |
549 |
570 |
591 |
|
C |
HT length (mm) |
105 |
130 |
155 |
180 |
|
D |
CS length* (mm) |
428 |
428 |
428 |
428 |
|
E |
HT angle (°) |
69,5 |
71 |
72,5 |
72,5 |
|
F |
ST angle (°) |
74 |
73,5 |
72,5 |
72,5 |
|
G |
Reach (mm) |
365 |
376 |
387 |
401 |
|
H |
Stack (mm) |
522 |
551 |
580 |
604 |
|
|
Stem (mm) |
80 |
80 |
90 |
100 |
|
|
Crank length (mm) |
170 |
170 |
170 |
170 |
